The Role of ultrasound and Magnetic Resonance Imaging in the Evaluation of Musculotendinous Pathologies of the shoulder Joint
Article Sidebar
Views | PDF/EPUB Downloads:
69
/ 7
/ 5
Main Article Content
Abstract
Aim: To evaluate and characterize the musculotendinous pathologies of shoulder joint using ultrasound (USG) and magnetic resonance imaging (MRI).
Background and Objectives: The glenohumeral joint, being the most mobile and unstable of all the joints, is often prone to injuries. To compensate for its unstable bony anatomy, the shoulder is protected anteriorly, posteriorly, and superiorly by a capsule and tendons that form the rotator cuff. Sonography is often considered the first-line imaging modality in the assessment of cuff as well as in nonrotator cuff disorders. MRI is of value in cases of extensive abnormality that is often incompletely characterized by the initial sonographic examination, as in case of sonographically inaccessible areas. However, musculoskeletal imaging is truly a multimodality approach and in order to identify and characterize the lesion, a combination of modalities should be used.
Materials and Methods: A prospective study was carried out on 75 patients in the Department of Radiodiagnosis, Padmashree Dr. D. Y. Patil Medical College, Hospital and Research Centre, Pimpri, Pune over a period of 2 years from July 2011 to September 2013. Patients from all age groups including both men and women with shoulder pain, suspected to be arising from the musculotendinous tissues of the shoulder joint, were taken up for study.
Results: In our study, USG showed a sensitivity of 95.2%, specificity of 88.8%, and positive predictive value of 80% for demonstrating full-thickness tears. In case of partial-thickness tears, USG showed overall sensitivity of 94.7%, specificity of 85.7%, and positive predictive value of 90%. Overall accuracy of USG in detecting full-thickness as well as partial-thickness tears was 91%.
Conclusion: In patients with shoulder complaints, USG is a reliable dynamic diagnostic tool. It reveals high diagnostic accuracy in detecting rotator cuff pathologies including cuff tears and tendinopathy. However, MRI has always been successful in overall assessment of joint structure. Its ability to evaluate labrum and various glenohumeral ligaments cannot be superseded by USG.
Downloads
Article Details
Section
This work is licensed under a Creative Commons Attribution-NonCommercial 4.0 International License.
This is an open access journal, and articles are distributed under the terms of the Creative Commons Attribution-NonCommercial-ShareAlike 4.0 License, which allows others to remix, tweak, and build upon the work non-commercially, as long as appropriate credit is given and the new creations are licensed under the identical terms.
How to Cite
References
1. Chaurasia BD. BD Chaurasia’s Human Anatomy; 2010.
2. Luime JJ, Koes BW, Hendriksen IJ, Burdorf A, Verhagen AP, Miedema HS, et al. Prevalence and incidence of shoulder pain in
the general population; a systematic review. Scand J Rheumatol 2004;33:73‑81.
3. van Holsbeeck MT, Introcaso JH. Sonography of muscle. Musculoskeletal Ultrasound 2001:23‑75.
4. Martinoli C, Bianchi S, Prato N, Pugliese F, Zamorani MP, Valle M, et al. US of the shoulder: Non–rotator cuff disorders. Radiographics 2003;23:381‑401.
5. Jacobson JA. Musculoskeletal sonography and MR imaging: A role for both imaging methods. Radiol Clin North Am 1999;37:713‑35.
6. Adler RS, Finzel KC. The complementary roles of MR imaging and ultrasound of tendons. Radiol Clin North Am 2005;43:771‑807.
7. Hawkins RJ, Misamore GW, Hobeika PE. Surgery for full‑thickness rotator‑cuff tears. J Bone Joint Surg Am 1985;67:1349‑55.
8. Zlatkin MB, Reicher MA, Kellerhouse LE, McDade W, Vetter L, Resnick D, et al. The painful shoulder: MR imaging of the glenohumeral joint. J Comput Assist Tomogr 1988;12:995‑1001.
9. Codman EA. Complete rupture of the supraspinatus tendon. Operative treatment with report of two successful cases. Boston
Med Surg J 1911;164:708‑10.
10. Deutsch A, Altchek DW, Veltri DM, Potter HG, Warren RF. Traumatic tears of the subscapularis tendon: Clinical diagnosis, magnetic resonance imaging findings, and operative treatment. Am J Sports Med 1997;25:13‑22.
11. van Holsbeeck M, Strouse PJ. Sonography of the shoulder: Evaluation of subacromial‑subdeltoid bursa. AJR Am J Roentgenol
1993;160:561‑4.
12. Read JW, Perko M. Shoulder ultrasound: Diagnostic accuracy for impingement syndrome, rotator cuff tear, and biceps tendon
pathology. J Shoulder Elbow Surg 1998;7:264‑71.
13. Goldberg JA, Bruce WJ, Walsh W, Sonnabend DH. Role of community diagnostic ultrasound examination in the diagnosis of
full‑thickness rotator cuff tears. Anz J Surg 2003;73:797‑9.
14. van Holsbeeck MT, Kolowich PA, Eyler WR, Craig JG, Shirazi KK, Habra GK, et al. US depiction of partial‑thickness tear of the rotator cuff. Radiology 1995;197:443‑6.
15. Wiener SN, Seitz WH Jr. Sonography of the shoulder in patients with tears of the rotator cuff: Accuracy and value of selecting
surgical options. AJR Am J Roentgenol 1993;160:103‑7.
16. Teefey SA, Hasan SA, Middleton WD, Patel M, Wright RW, Yamaguchi K. Ultrasonography of the rotator cuff. A comparison
of ultrasonographic and arthroscopic findings in one hundred consecutive cases. J Bone Joint Surg Am 2000;82:498‑504.
17. Naredoe E, Aguado P, De Miguel E, Uson J, Mayordomo L, Gijon‑Baños J, et al. Painful shoulder: Comparison of the physical
examination and ultrasonographic findings. Ann Rheum Dis 2002;61:132‑6.
18. Crass JR, Craig EV, Feinberg SB. Ultrasonography of rotator cuff tears: A review of 500 diagnostic studies. J Clin Ultrasound
1988;16:313‑27.
19. Zehetgruber H, Lang T, Wurnig C. Distinction between supraspinatus, infraspinatus, and subscapularis tendon tears with ultrasound in 332 surgically confirmed cases. Ultrasound Med Biol 2002;28:711‑7.
20. Teefey SA, Rubin DA, Middleton WD, Hildebolt CF, Leibold RA, Yamaguchi K, et al. Detection and quantification of rotator cuff
tears: Comparison of ultrasonographic, magnetic resonance imaging, and arthroscopic findings in seventy‑one consecutive
cases. J Bone Joint Surg Am 2004;86‑A:708‑16.
21. de Jesus JO, Parker L, Frangos AJ, Nazarian LN. Accuracy of MRI, MR arthrography, and ultrasound in the diagnosis of rotator cuff tears: A meta‑analysis. AJR Am J Roentgenol 2009;192:1701‑7.
22. Rutten MJ, Spaargaren GJ, van Loon T, de Waal Malefijt MC, Kiemeney LA, Jager GJ. Detection of rotator cuff tears: The value
of MRI following ultrasound. Eur Radiol 2010;20:450‑7.
